How to Increase CNC Tool Life and Avoid Breakage
The modern manufacturing process requires that each CNC tool be kept in good condition to ensure high-quality output. This is because wear and tear and damage to tools may cause low productivity, poor surface finish, and high production costs. It doesn't matter whether you are working on a big or small scale; it is important to know how to take care of your investment in tooling.
What Causes CNC Tool Wear and Breakage?
The main reason for tool wear and breaking in CNC machining is due to excessive stresses produced through heat and mechanical actions in the cutting process. While tool wear is a gradual phenomenon, tool breaking is a sudden event usually caused by heavy loading, vibrations, or tool wear progression.
Main Causes of CNC Tool Wear
Tool wear is progressive wear experienced at the rake face or the flank face due to friction and chemical reactions.
Wrong Speeds and Feeds: Fast spindle speeds will "cook" the cutting edge by the frictional heat that builds up, whereas slow feed rates make the tool rub on the metal rather than cut it, thus speeding up the abrasive wear.
Extreme Thermal Load: This results from continuous contact, which creates extreme temperatures. If not properly cooled, the high temperature will soften the binding agent (cobalt) of the tool (tungsten carbide) and cause it to deform quickly.
Wrong Tool Materials: Using uncoated tools or the wrong substrate on extremely abrasive materials, such as titanium and stainless steel, is one major cause of abrasive and diffusive wear.
Workpiece Abrasiveness: Hard inclusions and scaling, or the inherent nature of the work-hardened metal, will wear out the tool shape through physical abrasion.
Types of CNC Tool Wear You Should Know
The classification of CNC tools based on their wear takes place by considering the location of the wear on the tool and the mechanism involved in its occurrence. This can help operators make necessary adjustments to the speed, feed or coating of the tool before a tool failure occurs.
1. Flank Wear
This refers to wear that happens along the flank of the tool; this is the side part of the tool in contact with the completed workpiece.
- Mechanism: Mechanical abrasion
- Description: Flat shiny strip along the cutting edge.
- Primary cause: Friction caused by normal usage of the tool.
- Contributing factors: High cutting speeds, abrasive workpiece materials.
2. Crater Wear
It occurs on the top of the tool, the rake face, where the chips are peeled off the material.
- Mechanism: Chemical diffusion and mechanical abrasion.
- Description: Concave pit on the top surface of the cutting edge.
- Primary cause: Intense heat leading to tool material softening, hence causing chips to peel away.
- Contributing factors: No coolants, high feed rates, reactive metals such as titanium.
3. Chipping and Notch Wear
The chipping phenomenon involves the separation of discrete and microscopic pieces of material from the cutting edge, whereas notch wear results in the formation of a groove in the region of the depth of cut.
- Mechanism: Mechanical fatigue due to stress concentration.
- Appearance: Micro notches or cracks formed on the cutting edge.
- Cause: Intermittent stresses, cutting hard scale or vibration.
4. Built Up Edge (BUE)
The built-up edge occurs when the material of the workpiece attaches itself to the cutting edge of the tool.
- Mechanism: Adhesive bonding.
- Appearance: Material adhering to the cutting edge of the tool.
- Cause: Low temperatures with low speed and high pressures.
Causes acceleration: Machining of ductile materials such as aluminium and soft stainless steel under no-lubrication conditions.
The Risk: The chunk eventually separates, causing microscopic chips to separate from the tool.
5. Thermal Cracking
Thermal cracking consists of micro-cracking that forms perpendicularly to the cutting edge as a result of frequent temperature changes.
- Mechanism: Thermal fatigue.
- Visual sign: Series of fine cracks along the cutting edge.
- Contributing factors: Intermittent cutting operations combined with irregular distribution of the cooling medium (sudden chilling of the tool).
- Major cause: Rapid temperature changes between extremes.
6. Plastic Deformation
This condition develops because of the failure of the structural binder of the tool matrix under enormous pressure and temperature changes, resulting in a change in the shape of the tool tip.
- Mechanism: Structural softening.
- Visual sign: Slumping or mushrooming of the tool tip.
- Major cause: The cutting edge gets overheated and consequently softened and deformed under pressure.
- Contributing factors: Very high cutting speed, large feed, inappropriate tool material (uncoated grade).
7 Proven Ways to Prevent CNC Tool Wear
1. Optimise Cutting Speed & Feed Rate
Choosing the right cutting parameters is one of the most effective ways to prolong tool life.
- Avoid overly high speeds that cause too much heat generation
- Maintain proper feed rate for easy cutting
- Always use manufacturer-recommended settings
Parameter optimisation helps improve tool performance and avoid any stress on the CNC tool.
2. Select Proper Coolant
Coolant can significantly reduce friction and heat.
- Choose an appropriate coolant based on the material being machined
- Make sure it flows properly in the right direction
- Monitor the quality of coolant regularly
Effective cooling improves both tool life and machining efficiency.
3. Select the right tool material
The type of material affects the longevity of the tool.
- Select a quality carbide insert for hard materials
- A coated tool should be used for high-speed applications
- Tool material should match workpiece material characteristics.
4. Maintain Machine Stability
There should be stability to reduce vibration and uneven loads.
- Proper tightening of tools
- Calibration of machines
- No excessive overhang on the tool
It will assist in maintaining accuracy and preventing any tool breakdown.
5. Inspection of Tool Conditions
Regular inspection can make early detection possible.
- Measurement of tool dimensions
- Replacement of tools before total breakdown
- Observance of a routine tool inspection program
- This will save time and money.
6. Utilisation of Good-Quality Cutting Tools
Utilisation of quality tools increases their efficiency.
- Good quality drills for producing holes
- Utilisation of premium quality tools for longer processes
- Avoid cheap and poor-quality tools
This way, there will be no problem during the utilisation of such tools.
7. Apply Proper Tool Path Strategies
Programming efficiently prevents undue stress.
- Do not make abrupt directional changes
- Use smooth cutting tool motions
- Ensure proper entry/exit of the cut
Programming well increases not only tool life, but machining precision.
Common Programming Errors to Avoid
Not making any of these mistakes will greatly decrease wear and breakage:
- Using tools at full speed without trial runs
- Overlooking coolant maintenance
- Using dull tools on important cuts
- Inadequate storage or handling of tools
- Failing to maintain machines regularly
These simple mistakes can cause big problems down the road.
Tips to Extend CNC Tool Life
The longevity of tool life entails both appropriate practices and constant observation.
- Adhere to the correct cutting data
- Ensure that your tools are cleaned and kept properly
- Replace your tools at the right moment
- Educate your personnel regarding appropriate usage practices
- Maintain consistency in the conditions used when machining
By heeding these pointers, you will benefit significantly.
Jaibros – A Reliable CNC Tool Supplier
Jaibros is one of the most reputable CNC tool suppliers in India. Offering a wide variety of CNC machining solutions, including various tools and accessories, ensures durability, accuracy, and reliability. Whether you require premium carbide inserts, performance drills, or complete CNC machine tools, their site provides you with dependable products for the professional.
FAQs
1. Why do the uses of CNC tools become worn out?
The first reason for that phenomenon can be named as too much heat because of using the wrong parameters of the process.
2. How often does one have to inspect their tools?
It is necessary to do that regularly while working, especially when working with high precision.
3. Why is it essential to use coolants when machining?
Because coolants help reduce temperature and friction, which can harm both parts and tools.
4. Can tool wear influence the quality of products?
Of course, the weariness causes many problems in the quality of machined parts.
5. How can you avoid breaking the tools?
It is possible when choosing the right parameters and material of tools.
Conclusion
It is very important to ensure that wear and breakage do not occur because of the benefits it brings about. This is done through learning the different causes of wear and types of wear. The different ways to deal with wear and tear in machining will be analysed in order to improve machining performance.
